DJI O4 Air Unit Pro Video Transmitter

DJI O4 Air Unit PRO Specifications:

Sensor: 1/1.3-inch CMOS sensor

FOV: 155° ultra-wide

4K/120fps video

Aperture: f/2.8

Focus: 0.6m to ∞

Video format: MP4

1080p/100fps live view

Mounting holes: 25.5*25.5mm / 20*20mm

Camera center distance: 16mm

15μs digital video transmission 15km

Flagship FHD FPV Digital Video Transmission

Compatible with DJI Goggles 3, DJI Goggles N3; DJI Goggles 2 and DJI Goggles Integra

Weight (camera + drone): ~32 g

Weight (module): ~15.6 g

Antenna weight: ~2.1 g (1 pc.)

Transmission module dimensions: 33.5*33.5*13 mm

Camera module dimensions: 25.55*20*23.3 mm

Coaxial cable: 140 mm

3-in-1 cable: 100 mm

Antenna: 110 mm

Operating frequency: 5.170-5.250 GHz / 5.725-5.850 GHz

Transmitter power (EIRP): 5.1 GHz: <23 dBm (CE) / 5.8 GHz: <33 dBm(FCC); <14 dBm(CE); <30 dBm(SRRC)

Lowest Latency (with DJI Goggles 3): 15ms (1080p/100fps)

Lowest Latency (with DJI Goggles N3): 19ms (1080p/100fps)

Lowest Latency (with DJI Goggles 2& Integra): 30ms (1080p/100fps)

Input Voltage: 7.4-26.4V

Operating Temperature: -10° to 40°C

Built-in Storage: 4GB

Supports microSD (up to 512GB)

Flight Control System: Betaflight 4.3.0 and above

Size: 33mm x 33mm x 23mm

Price:

24500 грн

Переглянути відгуки (0)

With this product buy:


Power module PM02D (2S-12S)	CubePilot Here 4 CAN F9P RTK GNSS GPS Receiver	MPPT Controller 80 Amp Model S3-80A V124 MakeSkyBlue	GEPRC MATEN 1.2G 2W VTX Video Transmitter	Maple 1.2 GHz SMA-MALE Antenna (RHCP)

DJI O4 Air Unit PRO - digital video system for quadcopters

DJI O4 Air Unit PRO is a new product that is equipped with everything you need for impressive high-quality shooting. This digital system, thanks to advanced technologies, provides an extremely clear smooth image with minimal delay, allowing the pilot to fully immerse himself in the first-person flight. DJI O4 Air Unit PRO is endowed with high resolution and frame rate, which allows you to shoot video in 4K format, 120 frames per second for detailed smooth shooting. The lens with a viewing angle of 155 degrees allows you to capture the maximum area without losing any details.

Thanks to modern video transmission technology, the signal delay is minimal, so the pilot will feel comfortable during the flight. The video transmission system is compatible with DJI Goggles, allowing you to effectively use them in tandem for maximum immersion in flight. The intuitively simple interface and Betaflight support allow you to customize the system to your needs, and its small size and weight allow you to integrate it into any drone.
