Little bee BLHeli-s SPRING 30A ESC 2-6 S drone FPV controller

Little bee BLHeli-s SPRING 30A ESC 2-6 S drone FPV controller

  • input voltage: 2-6 S Lipo
  • constant current: 30A, breaking current: 35A to 10 S.
  • Support Muted mode, Oneshot125, Oneshot42 and Multshot and DSHOT
  • Main chip: SILABS EFM8BB21F16, MCU runs at 48MHz
  • MOS: both the low and high sides of the coupled transactions are Nfets
  • the switching speed is very fast, it has a special driver chip
  • BLHeli S bootloader and firmware
  • Size: 35mm x 17mm x 4mm
  • Count Price
    From1шт588грн
    From2шт577грн
    From9шт565грн
    From25шт559грн
    From67шт553грн
    Code: 1738
    шт.
    Є в наявності

    Переглянути відгуки (0)

    Little bee BLHeli-s SPRING 30A ESC 2-6 S drone FPV controller
  • Points to consider when using ESC:

    1: The battery voltage should not exceed 12S

    2: When you are not playing, after removing the battery, please turn off the ESC switch first (the switch should be in the OFF position).

    3: When driving forward at high speed and wanting to slow down, be sure to turn the remote control to the neutral position.

    Wait for a moment, then press the remote control in the direction of braking.

    That is, the vehicle must be slowed down before braking.

  • Features:

    LittleBee 30A S ESC BLHeli_S OPTO Electronic speed controller 2-6S Brushless for FPV Multi-copter

    Support for quadcopter Dampened mode, Oneshot125, Oneshot42 and Multshot

    MOS: both low and high sidebands are Nfets

    More radio controlled quadcopter racing products are provided by Crazepony on Amazon. Take a look at the sky and race like a free bird, enjoy an unparalleled first-person view.
