JHEMCU F4 NOXE V3 F411 Flight Controller 5V 10V BEC OSD Baro BlackBox 2-6S
Specifications:
Model: F4 NOXE V3
Main control (MCU): STM32F411CEU6/100 MHz
Sensor: BMI 270/Gyro/Accel
Video Overlay (OSD): AT7456E
Barometer (Baro): Yes (Deluxe version only)
Black Box (Black Box): 16MB (Deluxe Edition only)
Input voltage: Input voltage: 2S-6S (7.4V-26V)
5V-BEC: 5V/2.5A ± 0.1V
10V-BEC: 10V/2A+0.1V
Receivers (receivers): ELRs (CRSF), TBS (CRSF), SBU, IBU, DS M2, DS MX
HD interface: yes
UART: UART 1, UART 2
LIC: IIC1
LED strip: yes
Buzzer (buzzer): support 5V active
ESC signal (ESC signal): PWM, Oneshot125, Oneshot42, Multishot,
Dail 150, Dail 300, Dail 600
USB: Micro USB
Current terminal] (current port): yes
Voltage sensor (voltage sensor): Yes
Dfu button (dfu button): Yes
Firmware (Firmware): Betaflight_4.3.0 JHEF 411.HEX
Size: 27*27*5mm
Mounting hole: 20*20*3mm
Weight (weight): 4.3g Size: 27mm x 27mm x 3mm
Переглянути відгуки (0)
JHEMCU F4 NOXE V3 F411 Flight Controller 5V 10V BEC OSD Baro BlackBox 2-6S
About this item
The JHEMCU F4 Noxe has many features, it's a great choice for your next build!
JHEMCU products use only the latest PCB design and manufacturing technology for unparalleled performance and reliability.
This tiny board comes with tons of great features including built in OSD, barometer (Deluxe version only), built in BEC (5V, 10V), current sensor, buzzer, black box (Deluxe version only), WS2812 LED output, etc.!
Accessories: 1x flight controller JHEMCU F4 NOXE V3 F411 flight controller JHEMCU F4 NOXE V3 F411
